| Specifications |
| SOUND GENERATOR |
MTW I(Modelled Tone Wheel I)
61 polyphony (for manual)
3 polyphony (for pedal) |
| KEYBOARDS |
73 (61 + 12 Preset Keys)
Water Fall type
Virtual Multi Contact |
| HARMONIC DRAWBARS |
Drawbars
- Upper: 2 x 9 Pitches
- Lower: 2 x 9 Pitches
- Pedal: 2 Pitches
Voicing
- Manuals: 4 choices (A-100, B-3, C-3, Mellow)
- Pedal: 4 choices (Normal, Muted, Synth1, Synth2)
- Virtual Multi Contact |
| TOUCH RESPONSE PERCUSSION |
Buttons
- Percussion On, Th ird Harmonic, Fast Decay, Volume Soft
Adjustable
- Touch, Velocity, Decay (Fast, Slow), Level (Normal, Soft) |
| EFFECTS |
Vibrato and Chorus
- Digital Scanner
Tube Pre-Amp
- Device: 12AX7, 12AU7
- Adjustable: Routing, Level
Overdrive
- Control: On, Depth
Multi Effects
- 8 programs
Equalizer
- Bass, Mid, Treble, Tone
Internal Leslie
- Advanced Digital, 2 Rotors
- Buttons: Bypass, Stop, Fast
Reverb
- Digital, 11 programs
- Control: On, Depth
- Leslie On Reverb
Master Equalizer
- Bass, Mid, Treble |
| KEYMAP |
Buttons
- Pedal To Lower, Split, Transpose, Octave Down, Octave Up, Lower
Adjustable
- Coupler Highest note, Split Point |
| PATCHES |
Capacity
- 100 User Patches, 100 Factory Patches, Adjust Preset A#/B
Favorites
- 10 Keys
Patch Load Options
- Drawbar Registration, Drawbar Parameters, Internal Zone, External
- Zone, Eff ects, Reverb |
| CONTROLLERS |
Volume
- Master Volume
Switch
- Power On/Off |
| STORAGE |
USB Flash Drive |
| DISPLAY |
20 - Characters, 2 - Lines
7 Control Buttons and Value knob |
| MIDI |
Templates
- 5 Templates
Zones
- 3 External Zones (Upper)
- 2 External Zones (Lower)
- 1 External Zone (Pedal)
- and Keyboard Channels:
Upper, Lower, Pedal |
| CONNECTIONS |
MIDI
- In (Pedal), In (Lower/Other), Out
USB
- To Host
H-Bus
- To Keyboard/Pedal (0.3A max)
Audio
- Line Out L/Mono, R, Headphones (Rear, Bottom)
Leslie
- 11 - pin, 1 and 3 channels available
Others
- Leslie Switch, Foot Controller 1, 2, Exp. Pedal, AC Inlet |
| DIMENSIONS |
119(W), 40(D), 12(H) cm |
| WEIGHT |
15.7 kg |
